Detailed Description
The Anwetech AT-FR301 Remote Status Unit is an essential interface device for gas suppression systems, allowing users to monitor system status and operate key functions from outside the protected area.
It communicates with the extinguishing panel via RS485 bus and is powered by 24VDC auxiliary supply, supporting up to 7 remote units per system.
With clear LED status indicators—Fire, Release Imminent, Released, Fault, Disable, Hold Activated, Auto/Manual, and Power—the AT-FR301 ensures technicians and operators can verify fire system conditions at a glance.
A key-switch allows Auto / Manual mode selection, and authorised users can trigger emergency release via dedicated push button when needed.
Engineered with a steel enclosure (IP30) for durability, the unit is suitable for data centers, telecom rooms, server facilities, energy stations, industrial sites, and high-security environments using FM-200, N-1230, CO₂, or IG-541 suppression systems.
Key Features
EN12094-1 compliant remote status and control panel
RS485 communication; up to 7 units per extinguishing panel
LED indicators for fire, release, fault, disable, mode, and power
Auto / Manual mode key switch
Auxiliary 24VDC power input
Steel enclosure, IP30 rating
Suitable for critical clean-agent fire suppression systems
Applications
Data centers and server rooms
Telecom & UPS rooms
Industrial control rooms
Energy & power distribution facilities
Clean-agent fire suppression areas
